60Hz Diesel Power Genset 22kW Chinese Diesel Engine Generator For Emergency Use

Product Categories
FUJIAN TECGEN POWER CO., LTD.
Contact Now

60Hz Diesel Power Genset 22kW Chinese Diesel Engine Generator For Emergency Use

  • 1
  • 2

Brand Name : Tecgen Power

Model Number : TG28YDSD6

Certification : CE / SASO / SONCAP / COC / PVOC

Place of Origin : Fuzhou, China

MOQ : 1 unit

Price : Negotiation

Payment Terms : T/T, L/C

Supply Ability : 200 Units Per Month

Delivery Time : 7 - 15 Working Days

Packaging Details : Stretch film packaging or Polywooden Package

Frequency : 60Hz

Speed : 1800rpm

Cooling Method : Water Cooled

Alternator Type : AC Brushless Alternator

Prime output : 20kW

Max output : 22kW

Engine : YSD490D

HS Code : 8502110000

Contact Now

60Hz diesel power genset 22kW Chinese diesel engine generator for emergency use



Product Description for 60Hz Diesel Power Genset



Key Features:



  1. Powerful Chinese Diesel Engine: Equipped with a reliable Yangdong diesel engine, renowned for its powerful performance and durability.
  2. Efficient Alternator: Features a high-quality alternator that ensures stable and efficient power output for continuous operation.
  3. Smartgen Controller: Integrated with a Smartgen controller for automatic management and protection, ensuring smooth and safe operation.
  4. Silent/Super Silent Design: Minimizes noise levels, providing a quieter operational environment.





Standard Features:



  1. Forced Water Cooling System: Ensures optimal engine temperature for enhanced performance and durability.
  2. Overload & Short Circuit Protection: Prevents damage to the generator set, safeguarding against potential hazards.
  3. Easy Access Panels: Designed for convenient maintenance and repairs, reducing downtime and enhancing usability.



60Hz Diesel Power Genset 22kW Chinese Diesel Engine Generator For Emergency Use



22kW 60Hz Diesel Power Genset Specifications:



60Hz Diesel Power Genset Technical Datasheets
Genset model TG28YDSD6
Genset Type Silent / Super Silent
Rated Voltage 440V//415V/400V/380V/230V/220V/110V
Frequency 60Hz
Speed 1800rpm
Output Type AC Three Phase
P.F(COS) P.F. 0.8
Prime Output Current 69.7A
Prime Power 20kW / 25kVA
Standby Power 22kW / 28kVA
Diesel Engine Brand Yangdong
Model YSD490D
AC Alternator Brand Tecgen Power
Model TGI184S20
Genset Controller Brand Smartgen
Model HGM6110N
Genset Weight 880kgs
Genset Dimensions L2100 * W 900 * 1000
Fuel Tank Capacity 10 running hours
Yangdong Diesel Engine Data
Brand Yangdong
Engine Model YSD490D
Number of Cylinders 4 Cylinder in Line
Cycle 4-troke
Aspiration Natural Aspiration
Displacement 2.54L
Compression ratio 18:1
Bore×Stroke 90*100mm
Speed 1800rpm
Prime Power 25kW
Standby Power 28kW
Speed Governor MECH or Electrical
Cooling System Forced water cooling cycle
Starting system DC Motor
Fuel Consumption at 100% Load 247.5g/kwh@1800rpm
AC Alternator Data
Brand Tecgen Power
Model TGI184S20
Frequency/speed 60HZ/1800RPM
Rate Output 20kW
No. of Phase 3 Phase, 4 Wire
Exciter type Single bearing, Brushless, Self-excited with AVR
Power factor 0.8
Insulation Grade H
Protection Grade IP23
Working Condition Below 1000m
Bearing Single
Coupling Direct
Voltage adjust range ≥5%
Voltage regulation NL-FL ≤±1%
Genset Controller System
Controller System Brand Smargen
Model HGM6110N
Functions Auto Mains (Utility) Failure
Static with auto. battery charger
Emergency stop push button
ATS & RS485 Connection
CAN Functions
Diesel Generator Set Output ranges & Brand Options
Prime Power (kW) Diesel Engine AC Alternator Controller Type
8kW ~ 2400kW Cummins / Perkins / Deutz / Weichai / Yuchai / SDEC / Mitsubishi / Doosan / Wudong / Baudouin

Leroy Somer /

Stamford /

Mecc Alte /

Tecgen



 DEIF Open/Silent
7kW ~ 320kW Yangdong / FAWDE / Quanchai / YTO Tecgen Smartgen
11kW ~ 104kW Beinei Aircooled Tecgen
10kW ~ 300kW Weifang Ricardo Stamford DEEPSEA
6.8kW ~ 2000kW Caterpillar Caterpillar Caterpillar
6.8kW ~ 2000kW FG Wilson FG Wilson FG Wilson
17kW ~ 30kW Isuzu Mecc Alte ComAp
210kW ~ 818kW VMAN Tecgen Tecegn
6kW ~ 2000kW Chinese Engines Smartgen





Usage:


Ideal for a range of applications, including power backup, emergency power supply, and off-grid power solutions across various industries and settings.



60Hz Diesel Power Genset 22kW Chinese Diesel Engine Generator For Emergency Use



Options:



  1. Multiple Engine Brands: Choose from a variety of engines to suit your specific power requirements and budget.
  2. Customization: Customize the generator set according to your voltage, frequency, and output power needs for a perfect fit.





Warranty:


Offered for 18 months or 1500 hours, whichever comes first, providing peace of mind and ensuring long-term reliability.





FAQ:



  • Q: What is the warranty period for the generator set?
    A: The warranty period is 18 months or 1500 hours, depending on which comes first.
  • Q: Can the generator set be customized?
    A: Yes, we offer customization options to meet your specific power requirements.



With its robust Chinese diesel engine and high-quality alternator, our 60Hz diesel power genset is the ultimate choice for reliable and efficient power supply. Contact us today for more information and ordering details!
